Mission LX CONNECT, wireless speaker system couples innovative wireless technology, an award-winning loudspeaker series and versatile hi-fi grade connectivity options for a ‘True Wireless’ speaker system and a new level of convenience and performance that changes the game for wireless speaker systems.

LX CONNECT offers wireless connectivity via an advanced wireless hub which hosts all of the connectivity options for your listening pleasure. The LX CONNECT HUB intelligently transmits left and right audio signals to the appropriate speaker via uncompressed, 5.8Ghz wireless audio signal transmission. There is no trailing cable between speakers or hub with no need for the speakers to be connected together via a cable, for ‘True Wireless’ audio.The speaker system is based on the Mission LX-2 MKII speakers, with specially engineered, high-power digital amplification modules offer 50w from each cabinet (100w per system). Following the LX MKII series design and performance, the LX CONNECT speaker maintain the Mission trademark ‘Inverted Driver Geometry’ design and precision-tuned crossover to yield improved transient attack and astonishing detail. Mission DiaDrive bass units offer superior control of the low-frequency diaphragm while a refined high-frequency performance and a re-engineered cabinet bracing system further help create a loudspeaker system that outperforms its price-class.

The LX CONNECT HUB, which acts as the central console for all of your music sources; including analogue, optical and coax digital inputs. The LX CONNECT HUB is a high-specification, standalone audio hub in it’s own right. There is a dedicated HDMI ARC connection to bring high fidelity, true wireless performance for TV, movies and games, and Bluetooth aptX connections for wireless streaming of hi-resolution audio from tablets and smartphones.

The LX CONNECT HUB also doubles as a high performance USB DAC, equipped with the ESS Sabre32 ES9018K2M Reference DAC, and hi-fi grade headphone amplifier that will outperform most dedicated headphone amp / DAC combinations in this price-point, alone! Unlike other wireless and active speakers where controls and inputs are often placed awkwardly on the back panel, the LX CONNECT HUB is easily controlled via the tactile interface and LCD display or, for even more convenience, you can use the included remote.

Sporting fantastic new Lux Black and Lux White, as well as classic Walnut Pearl finish options for the speakers; the Mission LX CONNECT is a truly wireless speaker that represents an expertly presented audio experience for hi-fi lovers, gamers and contemporary digital music enthusiasts, alike.

Wireless Connection

• The LX CONNECT speakers and hub work wirelessly; completely independently of each other, with no interconnects
• Uncompressed true wireless operation, with 20 meters wireless range
• No amplifier or AV receiver is needed
• Ultra-quick and one-touch set-up

Audiophile Hub Spot

• Audiophile grade input connectivity options
• ESS Sabre32 ES9018K2M Reference DAC for USB connection
• Optical, coaxial and RCA inputs
• Bluetooth aptX receiver (play audio from smartphones, tablets and computers)
• HDMI ARC input for TV / Movie / Gaming applications
• Audiophile grade headphone amplifier with 6.3mm headphone output
• Detailed onboard LCD display and tactile control
• Change source / volume control and menu parameters
• with the included remote, or use the tactile controls of LX CONNECT HUB itself

LX in the Blood

• Based upon the award-winning Mission LX-2 MKII speakers
• Built-in 50W class D amplification and onboard DSP
• Speaker sensitivity (2.83V @1m) is 87dB, with frequency response 55Hz to 20kHz
• Custom designed serrations in the driver surrounds to help scatter interfering reflections from localised surfaces to the dome and cone
• Mission’s classic IDG (Inverted Driver Geometry) driver format positions the high frequency below the
• bass / midrange driver meaning the length of path is equalised so the sound waves coincide at the listener’s head height. A proprietary principle that improves ‘time alignment’ and thus transient performance in Mission speakers
• Standout new finish options follow the Mission mantra of fusing Hi-Fi heritage with contemporary design. LX MKII is beautifully finished in a choice of walnut pearl, and the latest Lux Black and Lux White matte finishes

General Description

• Wireless Speaker System

Design Philosophy And Core Technology

• 5.8GHz Wireless Uncompressed
• Technology
• DAC ESS Sabre 9018
• Support Music And Movie Mode
• Headphone Amplifier
• Support USB Upgrade
• Pre Delay Setting
• Roon Tested
• Touch Control

Analogue Input

• RCA (AUX)

Digital Input

• OPT, COAX, PC USB, Bluetooth,
• AV Audio

Analogue Output

• RCA Pre Out

Pre Amplifier (hub)

• Hub

Input Sensitivity

• 300mV (AUX IN, volume = MAX)

Input Impedance

• 13K (AUX IN)

Variable Output Voltage

• 0 – 3.2V

Output Impedance

• 100 ohm

Frequency Response

• 20Hz-20kHz (+/-0.3dB)

Signal-to-noise Ratio (S/N)

• > 100dB (AUX IN, A-weighted)
• > 110dB (digital Inputs, A-weighted)

Total Harmonic Distortion

• < 0.001% (digital sources )
• < 0.005% (analogue sources)

Sampling Rate

• 24bit - 192kHz (OPT, COAX)
• 32bit - 384kHz (USB, PCM)
• 2.8M for DSD64, 5.6M for DSD128,
• 11.2M for DSD256 (USB, DSD)

Digital Filters

• Fast Roll-off, Slow Roll-off,
• Minimum Phase

Active Speakers >

Enclosure Type

• Bass Reflex

Transducer Complement

• 2-way

Drive Unit >

Bass Unit

• 130mm Composite Fibre Cone

Treble Unit

• 25mm Microfibre Dome

AV Shielded

• No

Rated Power Output

• 60W

Peak Power Output

• 100W

Peak SPL

• 99dB

Frequency Response (+/-3dB)

• 58Hz – 20kHz

Bass Extension (-6dB)

• 52Hz

Crossover Frequency

• 3.2kHz

Wireless Reception Distance

• 20m

Cabinet Volume

• 8.2L

Dimensions >

Height (on feet)

• 305mm

Width

• 200mm

Depth (with terminals)

• (250+15)mm

System >

Carton Size

• 545 x 440 x 400mm

Net Weight

• 6.55kg x 2 (speakers)
• 1.75kg (hub)

Gross Weight

• 17.8kg

Finish

• Walnut Pearl / Lux White / Lux Black (speakers); Black (hub)

Power Requirements

• 100-240Vac (50/60Hz)
